CHAPTER 3: CONTROL PANEL OPERATION
PR2: 05/09/12 Page 35 of 162
Benchmark 1.5LN Dual-Fuel Low NOx Boiler
Operation and Maintenance Manual
OMM-0041_0C
GF-121
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526-0288
(Bottom-Up).
3.5 SETUP MENU
The Setup Menu (Table 3-3) permits the operator to enter the unit password ( 159) which is
required to change the menu options. To prevent unauthorized use, the password will time-
out after 1 hour. Therefore, the correct password must be reentered when required. In
addition to permitting password entries, the Setup Menu is also used to enter date and time,
units of temperature measurements and entries required for external communication and
control
of the unit via the RS-232 port. A view-only software version display is also provided to
indicate the current Control Box software version.
NOTE
The Outdoor Temp display item shown with an asterisk in
Table 3-2 will not be displayed unless the Outdoor Sensor
function has been enabled in the Configuration Menu
(Table 3-4).
Table 3-2: Operating Menu
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Status Message
Active Setpoint 40°F 240°F
AIR Temp -70°F 245°F
Outdoor Temp* -70°F 130°F
Valve Position In 0% 100% Valve Position
Flame Strength 0% 100%
Run Cycles 0 999,999,999
Run Hours 0 999,999,999
Fault Log 0 19 0
Table 3-3. Setup Menu
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Passsword 0 9999 0
Language English English
Time 12:00 am 11:59 pm
Date 01/01/00 12/31/99
Unit of Temp Fahrenheit or Celsius Fahrenheit
Comm Address 0 127 0
Baud Rate 2400, 4800, 9600, 19.2K 9600
Software Ver 0.00 Ver 9.99
