Aerco, Benchmark 1.5ln dual-fuel low nox boiler, Gf-121 – AERCO BMK 1.5 LN Dual Fuel Feb 2013 User Manual
Page 125
APPENDIX F: PART AND DIMENSIONAL DRAWINGS
PR2: 05/09/12 Page
125 of 162
Benchmark 1.5LN Dual-Fuel Low NOx Boiler
Operation and Maintenance Manual
OMM-0041_0C
GF-121
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526-0288
REAR
REV
AERCO
INTERNATIONAL
, INC
.
NORTHVALE
, NJ
07647
BENCHMARK
1.
5
LOW NOx
GAS FIRED BOILER
ANCHOR BOLT LOCATION
SD
- A
- 730
A
DRWN BY
: SJD
DATE
: 10
/12
/07
*NOT TO SCALE
*
FRONT
NOTES
: 1
) ALL HOLES ARE FLUSH WITH THE BOTTOM SURFACE OF THE FRAME 2)
ALL DIMENSIONS SHOWN ARE IN INCHES
(CENTIMETERS
)
