APPENDIX F: PART AND DIMENSIONAL DRAWINGS
Page 126 of 162 PR2: 05/09/12
Benchmark 1.5LN Dual-Fuel Low NOx Boiler
Operation and Maintenance Manual
OMM-0041_0C
GF-121
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526-0288
REV
AERCO
INTERNATIONAL
, INC
.
NORTHVALE
, NJ
07647
SD
- A
- 732
A
DRWN BY
: SJD
DATE
: 10
/12
/07
*NOT TO SCALE
*
79
"
18
"
101
"
44
.5
"
SIDE VIEW
TOP VIEW
INSTALLATION CLEARANCES
:
1)
THIS APPLIANCE MAY BE INSTALLED ON COMBUSTIBLE FLOORING
2)
MINIMUM CLEARANCES TO ADJACENT CONSTRUCTION ARE AS FOLLOWS
:
LEFT
&
RIGHT SIDES
: 24
"
FRONT
: 24
"
REAR
: 42
" *
CEILING HIEGHT
: 101
"
BENCHMARK
1.
5
LOW NOx
GAS FIRED BOILER TWO UNIT
ZERO SIDE CLEARANCE INSTALLATION
24
"
REAR
FRONT
24
"
24
"
56
"
NOTES
:
*1
) REAR CLEARANCE MAY BE REDUCED TO
30
"
DEPENDENT UPON
PIPING AND VENTING COMPONENT SELECTION
, ARRANGEMENT
,
AND LOCAL CODE REQUIREMENTS 2)
THE INNER SIDE PANELS MUST BE
REMOVED FROM BOTH UNITS FOR ZERO SIDE CLEARANCE INSTALLATIONS 3)
THE ZERO SIDE CLEARANCE OPTION
CAN ONLY BE EMPLOYED IN TWO UNIT SETS
42
" *
