TPS1100 - User Manual 2.2.1en

System functions

(Applies only to motorized
instruments)

The telescope is automatically
pointed at the latest point to be
stored. This function is available only
if a point was stored after switching
on the instrument.

Positioning the last point stored (LAST)

[>FREE]

This function activates
the vertical angle mode
"Running" for the
following measurements.
In this mode, the vertical
angle is continuously
updated with the
telescope movement.

After a distance
measurement, vertical angle,

slope distance, height difference, and
the elevation coordinate are
displayed as running values. Slope
distance, height difference, and the
elevation coordinate of the target
point are calculated from the initial
horizontal distance and currently
displayed vertical angle. The REC-
function records the displayed values
in the measurement file.

V-angle modes

[>FIX]

This function activates
the vertical angle mode
"Hold after DIST" for the
following
measurements. In this
mode, the vertical angle
is fixed after a distance
measurement, whereas
the horizontal angle is
running.

Function [VRUN]

This function deletes the last
measured distance and so releases
the locked vertical angle.

(Available only with special
configuration.)
