37
TPS1100 - User Manual 2.2.1en Checking and adjusting
6
10
12
21
Line of sight, continued
Confirms readiness for
measurement and goes to
the measuring menu.
Sight the target accurately.
Perform the second
measurement.
Stores the new values.
Repeats the complete line-of-
sight error determination
procedure.
Leaves the old values
unchanged.
If the value of the line-of-
sight error (c) exceeds 5' 24"
(0.1 gon), the collimation error is to
be redetermined. If the limit is
repeatedly exceeded, please notify
service.
When the new line-of-sight error has
been confirmed, the tilting-axis error
can be determined.
Confirms that the tilting-axis
error should also be
determined.
Ends the function and returns
to the calibration dialog.
After successful completion of the
second measurement, the older and
the newly-determined line-of-sight
errors are displayed.
Main\ Hz-Collim. Error
old new
c Hz-c: -0°00'03" 0°00'08"
Accept new value(s)?
YES RETRY NO
MC
QUIT
Main\ Hz-Collim. Error
YES NO
MC
Continue to determine the
tilting-axis errror?
Telescope Positioning
Hz- and V-positioning:
set direction(s) to zero.
∆∆∆∆∆ Hz : 0°00'00"
∆∆∆∆∆ V : 0°00'00"
OK ABORT
MC
QUIT
Main\ Hz-collim. Error
Aim accurately at the same
target in other face
Hz : 193°19'24"
V : 269°08'45"
MEAS
MC
QUIT
