EDM test
Toggles between the displays
of measurement frequency
and signal strength. The
measurement frequency display is
similar to the display shown above.
End and return to the
previous dialog.
ON/OFF - key for the acoustic tone.
The stronger the signal the more the
black intensity bar is extending to the
right against 100%. With an already
low signal distances can be
measured.
Displays the signal strength or
measurement frequency.
\ EDM Return Signal
Signal strength
0% 100%
75%
Tone : OFF▼ ▼ ▼ ▼ ▼
CONT FREQ STOP
MC
QUIT
Distance corrections, ppm
A distinction is made between
atmospheric (ppm) and geometric
(ppm) corrections, the sum of which
is used as the final distance
correction.
Settings for the geometrical
correction.
Atmospheric correction
The atmospheric distance
corrections are derived from the dry-
air temperature, air pressure or
height over mean sea-level, and rela-
tive air humidity or wet-air
temperature.
\ ATMOSPHERIC CORR.
Temperature : 12.0 °C
Atm. press. :1013.3 mBar
Temp.wet-b. : 60.0 %
ppm atmospheric : 0.0
ppm geometric : 0.0
ppm total : 0.0
CONT GEOM REFRA P<>E %<>T' ATM=0
MC
QUIT
The user can freely define the name
and additive constant (additive
constant) for three reflectors and can
enter the type of reflector (prism or
retro tape). The additive constant is
always given in millimetres [mm]. It is
advisable to determine the additive
constant for "non Leica Geosystems
prisms" on a baseline by means of an
appropriate procedure.
For the reflector to be available for
choice, the reflector type may not be
"None".
\Define new reflector 1
Define type of reflector
Ref.1 Type : Not defined
Ref.1 Name : -----
Ref.1 Cons : ----- mm
CONT
MC
QUIT
Setting / defining prisms, continued
