112 Data format TPS1100 - User Manual 2.2.1en
6
0
2
21
26
45
84
Word index (positions 1 - 2), continued
All words can be used in measurement blocks
except words 41 - 49, which are reserved.
A code block begins with 41, the word index for a
code number.
Information relating to data (positions 3 - 6)
Positions 3 to 6 contain information which relates to the
data in positions 7 to 15 (23).
Position
in word
Explanation Applicable to
3 Extension for word index Digital level
4 Compensator information
0 Automatic height index and
monitoring of levelling up: OFF
3 Automatic height index and
monitoring of levelling up: ON
All words
containing angle
information
5 Input mode
0 Value measured automatically
1 Manual input from keyboard
2 Angle: All Hz-corrections for Line
of sight error, tilting axis and tilt
of standing axis (only with
compensator: on): ON
Distance: Correction for
measurement to vertical prism
3 Angle: All Hz-corrections: OFF
4 Result calculated from functions
All words
containing
measured data
Word index Description
Distance
(additional
information)
51
52
53
58
59
Constants (ppm,mm)
Number of measurements, standard
deviation
Signal strength
Reflector constant (1/10 mm) ppm
Point coding
71
72 - 79
Point code
Attrib. 1-8
Coordinates
81
82
83
84
85
86
87
88
Easting (target)
Northing (target)
Elevation (target)
Station easting (Eo)
Station northing (No)
Station elevation (Ho)
Reflector height (above ground)
Instrument height (above ground)
