114 Data format TPS1100 - User Manual 2.2.1en
6
0
2
21
26
45
84
Separating character (position 16/24)
The last data word of a block must also contain
the separating character and CRLF.
Each data block is allocated a block number by the
recording device. Block numbers start at 1 and increment
automatically.
The block number is contained in the first word of the
block. The first word of a measurement block is the point
number (WI = 11). The first of a code block is the code
number (WI = 41).
The structure of the first word of a data block is as
follows:
Block number
Position
in word
Explanation Applicable to
16 (24) Blank (separating character) all words
Position in
word
Explanation
1-2
3-6
7
8-15(23)
16(24)
Word index 11 or 41
Block number (assigned by recording device)
Sign + or -
Point number, code number or text
Blank = separating character
