68 System functions TPS1100 - User Manual 2.2.1en
Activates the tracking mode if
the measuring program
"Standard distance measurement"
was selected, or the rapid-tracking
mode if the measuring program "Fast
distance measurement" was
selected.
Calls the EDM test (signal
and frequency)
Stops the current measuring
program.
Calls the function " EDM
parameters".
Distance measurement, continued Selecting the EDM measuring program, target type and reflector
\ EDM parameters
Set EDM Prog for DIST/ALL
Target Typ : IR=Reflector
EDM Prog. : Standard IR
Refl.Name : Leica circ.prism
Add.const.: 0.0 mm
CONT REFL
MC
QUIT
Infrared:
Standard IR
Normal distance measurement.
Accuracy 2mm+2ppm.
Measuring time 1.0 seconds.
Standard Fast IR
Rapid distance measurement.
Accuracy 5mm+2ppm.
Measuring time 0.5 seconds.
Tracking IR
Continuous measurement.
Accuracy 5mm+2ppm.
Measuring time 0.3 seconds.
Tracking Fast IR
Continuous measurement.
Accuracy 10mm+2ppm.
Measuring time <0.15 seconds.
Average IR
Repeat measurements in standard
measuring mode with display of the
number of distance measurements
(2
≤ n ≤ 999), the current average and
the standard deviation for the
averaged distance.
Very short distances may
be measured reflectorless
in Infrared-mode (e.g. to well
reflecting targets like traffic signs).
In this case the distances are
corrected with the addition
constant defined for the active
reflector.
Reflector-free and long range:
(red laser)
Standard Long RL
Normal distance measurement.
Accuracy 3mm+2ppm.
Average Long RL
Repeat measurements in normal
measuring mode
