TPS1100 - User Manual 2.2.1en Data format
6
10
12
21
26
45
84
The GSI data format does not contain a decimal point.
On transferring data to the computer, the decimal point must be inserted by
the computer in accordance with the units indicated in position 6 of the word.
Units of measurement
This section describes the types of
data measured and transmitted by an
electronic theodolite.
Example of data format
Position 6
in data
word
Units Places
before point
Places after
point
Example
0 Metre (last digit = 1mm) 5 3 12345.678
1 Feet (last digit = 1/1000ft) 5 3 12345.678
2 400gon 3 5 123.45670
3 360° decimal 3 5 123.45670
4 360° sexagesimal 3 5 123.45120
5 6400mil 4 4 1234.5670
6 Metre (last digit =
1/10mm)
4 4
1234.5678
7 Feet (last digit =
1/10000ft)
4 4
1234.5678
8 Metre (last digit =
1/100mm)
3 5
123.45678
