TPS1100 - User Manual 2.2.1en Technical specifications
6
10
12
21
26
45
84
92
Standard
prism
3 prisms
(GPH3)
360°
reflector
Reflector tape
60mm x 60mm
Mini
prism
1
1800 m
(6000 ft)
2300 m
(7500 ft)
800 m
(2600 ft)
150 m
(500 ft)
800 m
(2600 ft)
2
3000 m
(10000 ft)
4500 m
(14700 ft)
1500 m
(5000 ft)
250 m
(800 ft)
1200 m
(4000 ft)
3
3500 m
(12000 ft)
5400 m
(17700 ft)
2000 m
(7000 ft)
250 m
(800 ft)
2000 m
(7000 ft)
Technical specifications
Distance measurement (infrared)
• Type
infrared
• Carrier wave 0.780 µm
• Measuring system special frequency system
basis 100 MHz = 1.5 m
• EDM type coaxial
• Display (least count) 1 mm
Atmospheric conditions:
1) Strong haze, visibility 5km; or strong sunlight, severe heat
shimmer
2) Light haze, visibility about 20km; or moderate sunlight,
slight heat shimmer
3) Overcast, no haze, visibility about 40km; no heat shimmer
Shortest measuring distance
• Standard prism
0.2 m
• Mini prism 0.2 m
• 360° Reflector 1.5 m
• 360° Mini prism 1.5 m
• Reflector tape 1.5 m
Measurements can be made to reflector tapes
over the entire range without external ancillary
optics (GDV3).
Range:
(normal and rapid measurement)
Prism constants (additive constants)
• Standard prism
0.0 mm
• Mini prism +17.5 mm
• 360° Reflector +23.1 mm
• 360° Mini prism +30.0 mm
• Reflector tape +34.4 mm
EDM measuring
programm
Accuracy **
Time per
measurement
Standard
measurement
2 mm + 2 ppm 1.0 sec.
Fast measurement 5 mm + 2 ppm 0.5 sec.
Normal tracking 5 mm + 2 ppm 0.3 sec.
Rapid tracking 10 mm + 2 ppm < 0.15 sec.
Averaging 2 mm + 2 ppm -----
** Beam interruptions, severe heat shimmer and moving
objects within the beam path can result in deviations of the
specified accuracy.)
