TPS1100 - User Manual 2.2.1en Technical specifications
6
10
12
21
26
45
84
92
Automatic Target Recognition ATR
Positioning accuracy
(TCA1102 / Standard prism, static,
ATR single measurement)
* in accordance with angle-
measuring accuracy
Prism use
• Standard prisms
Yes
• Mini prism Yes
• 360° reflector Yes
• 360° Mini prism Yes
• Reflector tape Yes
Special active prisms are not
required.
Recognition method
• Video techniques:
Yes
• EDM techniques: No
ATR
mode
LOCK
mode
Standard
prism
1000 m
(3300 ft)
800 m
(2600 ft)
Mini prism
500 m
(1600 ft)
400 m
(1300 ft)
360°
reflector
600 m
(2000 ft)
500 m
(1600 ft)
360°
Mini prism
350 m
(1150 ft)
300 m
(1000 ft)
Reflector
tape 60x60
65 m
(200 ft)
not qualified
Range
(under average conditions without
interruption of view)
Shortest measuring distance
(360°Refl.)
• ATR
1.5 m
• LOCK 5 m
Rotation and speed
Positioning
to 50 gon/sec
Follow a moving prism
(LOCK mode)
Typical search time
in telescopic field of
view
Normal
measurement =
2.5 sec + 1 sec
positioning
Full scope of search 1°30' (1.66 gon)
Scope of search
using remote control
18° (20 gon)
Interrupted viewing Yes, briefly
Searching
Tracking
?
Distance Max. tang. speed
No at 20 m 5 m/sec.
No at 100 m 25 m/sec.
Yes at 20 m 3.5 m/sec.
Yes at 100 m 18 m/sec.
Tracking
?
Distance Max. radial speed
Yes 0 to max.
distance
4 m/sec.
Distance Accuracy
Measuring
time
to 300 m 3 mm 3sec
> 300 m * 3 - 4
