TPS1100 - User Manual 2.2.1en System functions
6
10
12
21
26
Setting and entering the Hz direction (SetHz)
Activate the function "Set Hz to any
angle".
Target the tie point exactly.
The direction must always be set
using face I.
Set Hz direction to 0° 00' 00" (0.0000
gon) or enter a known value.
Sets Hz to 0° 00' 00"
(0.0000 gon).
Instead of entering a value, this can
be set by turning the instrument.
Secures the value (clamp the
circle)
Target the tie point exactly.
Releases the circle.
This function is also
activated from other dialogs
in order to enter the Hz direction.
Distance measurement
The following dialog is displayed
during the "first" distance
measurement:
\ Set Hz to any angle
Set Hz-direction
Hz :123°17'56"
SET Hz=0 HOLD
MC
QUIT
\ Distance Meas.
EDM Prog. : Standard IR
Refl.Name : Leica 360° prism
Add.const. : 23.1 mm
ppm total : 0.0
->Ref ->TRK TEST STOP EDM-P
MC
QUIT
The display shows the current
measuring program and reflector, the
current additive constant (prism
constant) and the total ppm value.
Switches between infrared
(with reflector,
! REF) and
red laser (no reflector, RL).
