TPS1100 - User Manual 2.2.1en Data format
6
10
12
21
26
45
84
Each word has a fixed length of 16
(24) characters.
Structure of a word
Position Meaning
1 - 2 Word index
3 - 6 Information relating to
data
7 - 15 (23) Data
16 (24)
Blank = separating
character
W1 w2 . . . . + 1 2 3 4 5 6 7 8 ↵ ↵↵ ↵↵
1 2 3 4 5 6 7 8 9 10 11 12 13 14 1516
Each word has a two-digit word index
to identify it. These two digits occupy
the first two positions of the word.
Word index numbers lie in the range
01 to 99.
The word indices are listed on the
following pages.
In some applications special word
indices are used. They are described
in the application manuals.
Word identification table
Word index (positions 1 - 2)
Word
index
Description
General
11
12
13
18
19
Point number (includes
block number)
Instrument serial number
Instrument type
Time format 1:
pos. 8-9 year,
10-11 sec,
12-14 msec
Time format 2: pos. 8-9
month, 10-11 day, 12-13
hour, 14-15 min
Angles
21
22
25
Horizontal circle (Hz)
Vertical angle (V)
Horizontal circle difference
(Hz0-Hz)
Distances
31
32
33
Slope distance
Horizontal distance
Height difference
Codebl.
41
42 - 49
Code number (includes
block number)
Information 1-8
