TPS1100 - User Manual 2.2.1en Data format
6
10
12
21
26
45
84
Information relating to data ( positions 3-6), continued
A point in any of the positions 3 to 6 means that
there is no information.
For the data words Point number (WI = 11) and Code
number (WI = 41), the block number occupies positions 3
to 6.
Data (positions 7 - 15/23)
Position
in word
Explanation Applicable to
6 Units
0 Metre (last digit = 1mm)
1 US-Feet (last digit = 1/1000ft)
2 400gon
3 360° decimal
4 360° sexagesimal
5 6400 mil
6 Metre (last digit = 1/10mm)
7 US-Feet (last digit = 1/10000ft)
8 Metre (last digit = 1/100mm)
All words
containing
measured data
Position
in word
Explanation Applicable to
7 Extension of word identification All words
8-15(23) The data comprises 8 (16)
numeric or alphanumeric
characters
Note that certain words can
contain two data blocks, i.e. pairs.
These are transferred
automatically, complete with signs,
from the survey instrument:
e.g. 0123 -035
ppm mm
All words
containing data
Words 51 - 59
