53
TPS1100 - User Manual 2.2.1en System functions
6
10
12
21
26
Number of GSI data found
\ Data View and Edit
17/20
Point Id : 17
Hz :286°12'36"
V :275°45'12"
Slope Dist : 123.236m
ppm tot/mm : +0051+000
CONT NEW S <-- --> <>
MC
|<<- ->>| DEL QUIT
Data management, continued
The data is displayed point by point in
accordance with the recording mask
in use at the time of the storage. The
data displayed can therefore change
from one point to another.
The assignations of the keys, and the
subsequent course of the program,
are the same as in the dialog "Data
View and Edit", with the exception of
the following function:
Deletes the displayed
data block from the file.
A message is called to confirm that
you want to delete the block.
This function searches in the current
data job for the coordinates of the
point required. It accepts the first
data set found after the start of the
file, but does not display this data set.
If no point data are found, a message
is displayed along with the note that
no points with this point number were
found.
With "NEW S", the dialog "File & Pt.
Selection" is called. The file for the
data search can be changed and/or a
new point number can be entered.
Or:
The missing data can be entered with
"INPUT".
Importing point data (IMPOR)
