KSN 765/770 Integrated Communication Navigation Display
D200802000009
REV 2 Jun 2014 15-159
Flight Management System (FMS)
Honeywell International Inc. Do not copy without express permission of Honeywell.
Stopwatch RESET -- The stopwatch reset touchscreen softkey
permits the pilot to reset the stopwatch timer back to the original value.
The stopwatch counter is displayed to the left of the RESET
touchscreen softkey.
Preset -- The Preset touchscreen softkey controls and displays the
preset value. How the preset value is used when the RESET
touchscreen softkey is selected depends on the stopwatch direction
(displayed in 1R). The preset value is always displayed when the
direction is DOWN , but toggles between cleared and displayed when
the direction is up.
When the direction key displays DOWN and the Preset touchscreen
softkey is pushed, the stopwatch alert is deactivated and a window is
displayed that permits the pilot to enter the desired stopwatch start
value.
When the direction key displays UP , pushing the Preset
touchscreen softkey clears the preset value and deactivates the
stopwatch alert. When the preset value is cleared and the direction
touchscreen softkey displays UP , pushing the Preset touchscreen
softkey displays a window which permits the pilot to enter the desired
stopwatch alert value.
When a preset time is reached on the stopwatch, the FMS message
TIMER EXPIRED is displayed.
START/STOP -- The START touchscreen softkey permits the pilot to
start the timer in 2R. The START touchscreen softkey changes to
STOP when selected. The STOP touchscreen softkey permits the
pilot to stop the timer in 2R. The STOP touchscreen softkey changes
to START when selected.
NOTE: When STOP is displayed, the direction in 1R and preset
value in 3R are not selectable until the stopwatch is stopped.
Back -- Pushing the BACK bezel softkey displays the Utility page.
