KSN 765/770 Integrated Communication Navigation Display
D200802000009
REV 2 Jun 2014 6-51
Navigation Map View
Honeywell International Inc. Do not copy without express permission of Honeywell.
Table 6--15 lists the selectable navigation map items and the associated
NAV map detail bezel softkey labels displayed.
Table 6--15
NAV Map Detail Control Bezel Softkey Labels
Graphical Symbol Bezel Softkey Labels
Airport
APT
COM
RWY
WX
(Displayed when XM WX is
configured.)
CHRT
(Displayed when the selected
airport has an associated
terminal procedure.)
VOR VOR
Intersection INT
NDB NDB
TFR TFR
Special Use Airspace SUA
Controlled Airspace ATC
NOTE: Only one NAV map detail control bezel softkey label can be
active at a time.
Pushing in the joystick knob or pushing the DETL bezel softkey
deactivates the NAV map detail control mode and returns to the NAV
map INFO view.
