BendixKing KSN 770 - Pilots Guide User Manual
BendixKing Air equipment

Highlights
Page 1 of 2
June 2014
Honeywell International Inc. Do not copy without express permission of Honeywell.
BendixKing By Honeywell
9201--B San Mateo Blvd. NE
Albuquerque, NM 87113
U.S.A.
CAGE: 6PC31
Telephone: 1--602--365--7027
Telephone: 1--855--250--7027 (Toll Free in U.S.A.)
TO:
HOLDERS
OF
THE
KSN
765/770
INTEGRATED
COMMUNICATION NAVIGATION DISPLAY PILOT’S GUIDE,
HONEYWELL PUB. NO. D200802000009
REVISION NO. 2 DATE JUNE 2014
HIGHLIGHTS
This revision is a full replacement. All pages have a new date, as
identified in the List of Effective Pages. Remove and discard all pages
of the manual and replace them with the attached pages.
