Figure 15-12 insert new waypoint pop-up window – BendixKing KSN 770 - Pilots Guide User Manual

Page 289

KSN 765/770 Integrated Communication Navigation Display

D200802000009

REV 2 Jun 2014

Flight Management System (FMS)

15-16

Honeywell International Inc. Do not copy without express permission of Honeywell.

Selecting

the

INS

bezel

softkey

displays

the

INSERT NEW WAYPOINT

pop--up window. KSFO is the desired

destination airport, however it is not displayed in the nearest airports

pop--up window. When a desired waypoint is not displayed in the

pop--up window, the waypoint can be manually entered by selecting the

manual input area just below the

INSERT NEW WAYPOINT

header,

then changing the characters one at a time using the joystick knob. The

joystick knob is then toggled left and right between the character fields

and the joystick knob is rotated to change the character in each field.

Alternatively, the touchscreen can be used to enter a desired waypoint

by selecting the waypoint identifier field, shown in Figure 15--12.

Figure 15--12

Insert New Waypoint Pop--Up Window
