KSN 765/770 Integrated Communication Navigation Display
D200802000009
REV 2 Jun 2014 13-11
Terrain Awareness and Warning System (TAWS) View
Honeywell International Inc. Do not copy without express permission of Honeywell.
TAWS Range Selection
The terrain view has a minimum range marker, a maximum range
marker, and two other incremental range markers. Figure 13--1 shows
the range markers as 10 , 20 , 30 , and 40 .
Table 13--2 lists the pilot--selectable ranges supported by the
KSN 765/770. The range of the TAWS view is controlled by the
zoom- out/+ and zoom- in/- bezel keys . The TAWS range selection
defaults to the last pilot--selection on power--up.
Table 13--2
TAWS Ranges
TAWS Range (NM) Settings
Range
Setting
Min.
Range
Marker
Range
Marker
(R1)
Ranger
Marker
(R2)
Max.
Range
Marker
1 1 2 3 5
2 2 5 7 10
3 5 10 15 20
4 10 20 30 40
5 20 40 60 80
6 40 80 120 160
7 60 120 180 240
8 80 160 240 320
If the selected TAWS range is not equal to the TAWS active received
range, RNG FLT is displayed in amber in the bottom--center of the
TAWS view.
