Technical details
Operating Manual PNOZ s50
1002194­EN­02 64
9.1 Safety characteristic data
Operating
mode EN ISO
13849­1:
2008
PL
EN ISO
13849­1:
2008
Category
EN IEC
62061
SIL CL
EN IEC
62061
PFH
D
[1/h]
IEC 61511
SIL
IEC 61511
PFD
EN ISO
13849­1:
2008
T
M
[year]
All PL e Cat. 4 SIL CL 3 7,83E­10 SIL 3 6,81E­05 20
All the units used within a safety function must be considered when calculating the safety
characteristic data.
INFORMATION
A safety function's SIL/PL values are not identical to the SIL/PL values of
the units that are used and may be different. We recommend that you use
the PAScal software tool to calculate the safety function's SIL/PL values.
The safety­related characteristic data (PFH, PFD) are mean values. They have been calcu­
lated at an average ambient component temperature of 40 °C and apply for the ambient
temperature range stated in the technical details.
