6.2.5 Display and configuration
6.2.5.1 Menu overview
The following diagrams illustrate the principle structure of the configuration menu on the
display.
The menu consists of
} Messages at cold start, if there are problems with the chip card.
} Level 1: Status indicators, error stack
} Level 2: Password entry
} Level 3: Configuration
The displayed symbols illustrate the operation of the rotary knob.
Rotate knob
Press knob
Level 1 and 2: Status indicators and password entry
Status information is displayed when the device is switched on. This level is not password­
protected.
The state of the signals is displayed as follows:
Icon Description
Signal inactive
Signal active
The password is entered in Level 2. It authorises configuration of the device in Level 3.
