Content
Operating Manual PNOZ s50
1002194­EN­02 4
6.1.7 Outputs 31
6.1.8 Feedback loop 31
6.2 Display menu and configuration 32
6.2.1 Operate rotary knob 32
6.2.2 Configure device 32
6.2.3 Password protection 33
6.2.4 Use chip card 33
6.2.4.1 Insert chip card 34
6.2.5 Display and configuration 35
6.2.5.1 Menu overview 35
6.2.5.2 Operate menus and enter values 38
6.2.5.3 Display menu at cold start 39
6.2.5.4 Status display and configuration 41
6.2.5.5 Restart device 47
Section 7 Operation 48
7.1 Display elements for device diagnostics 48
7.1.1 LED display 48
7.1.2 Display 49
7.1.2.1 Error stack entries 49
7.1.2.2 Current error messages 49
7.2 Reset I/O Fault 55
Section 8 Examples 58
8.1 Overview 58
8.2 Mechanical holding brake 58
8.2.1 Properties 58
8.2.2 Configuration overview 59
8.2.3 Connection 60
Section 9 Technical details 61
9.1 Safety characteristic data 64
Section 10 Supplementary data 65
Section 11 Order reference 66
11.1 Order references Module 66
11.2 Order references Accessories 66
Section 12 Appendix 67
12.1 Check list 67
