Commissioning
Operating Manual PNOZ s50
1002194­EN­02 44
Overview Display format Description
Switch to submenus
Config 1/3 Config 1/3
Load
Store
Reset Load – Switches to the Load menu to
download the configuration from the chip
card
Store – Switches to the Store menu to
save the configuration to the chip card
Reset – Switches to the Reset menu to
reset the configuration to the default set­
tings
Config 2/3 Config 2/3
Input
Feedback
Output Input – Switches to the Input menu to
configure the supply voltage for the power
element
Feedback – Switches to the Feedback
menu to configure the feedback loops
Output – Switches to the Output menu to
configure theproperties of the power out­
puts O1+/O1­ and O2+/O2­
Config 3/3 Config 3/3
Counter
Change PIN
Reboot Counter – Switches to the Counter menu
to enter a start value for the counter
Change PIN ­ Switches to the Change
PIN menu to change the password
Reboot ­ Switches to the Reboot menu to
restart the device
Load configuration from chip card
Load Config from
Card
Download paramet­
ers from the chip
card to the device
Load Config
from Card
Are you sure?
No Yes Are you sure? ­ Security prompt
No – Do not download parameters from
chip card
Yes – Download parameters from chip
card
Save configuration to chip card
Store Config to
Card
Download paramet­
ers from the device
to the chip card
Store Config
to Card
Are you Sure?
No Yes Are you sure? ­ Security prompt
No – Do not save parameters to chip card
Yes – Save parameters to chip card
Restore default settings
Reset Config to
Default
Reset configuration
to default settings
Reset Config
to Default
Are you sure?
No Yes Are you sure? ­ Security prompt
No – Do not load default settings
Yes – Load default settings
Configure supply voltage B1/B2 to the power circuits
Input
Switch to the menu
for the supply
voltage to the
power circuits
Input
B1/B2
B1/B2 – Switch to the Input Voltage
menu to configure the inputs B1/B2
