8 Examples
8.1 Overview
This chapter provides information on how to connect the PNOZ s50 to a safety control sys­
tem. The connections illustrated are independent of any specific control system.
INFORMATION
The following examples are intended to help you configure the application
using the display.
These settings and parameters should be regarded as example settings. It's
possible that your own specific application may require different settings or
parameters under certain circumstances.
CAUTION!
When considering the examples, please note that Pilz accepts no respons­
ibility for the specific application. In particular, they may not be used without
testing and approval.
The constructor is responsible for creating appropriate safety concepts for
the overall plant and for connection to the safety control system (including
configuration). The applicable standards and regulations must be con­
sidered and observed.
In each case it is necessary to consider the input and output requirements
from the chapter entitled "Function Description". This is also true when us­
ing the applied safety control systems.
8.2 Mechanical holding brake
8.2.1 Properties
PNOZ s50
} Safe activation of two independent mechanical holding brakes
} Ventilation and application times are monitored
} Fast and slow shutdown of both brakes
} Feedback loop for brake B1 is monitored via input Y1
} Feedback loop for brake B2 is monitored via input Y2
} Fuses
– F1: 24 V DC, 4 A, characteristic B/C
– F2: 24 V DC, 10 A, characteristic B/C
