Function description

Operating Manual PNOZ s50
1002194­EN­02

14

}

Switch­on (brake is ventilated):

O1+/O1­ is switched on when there is a "1" signal (24 VDC) at Y10 and Y11.

O2+/O2­ is switched on when there is a "1" signal (24 VDC) at Y20 and Y21.

Partial operation is not time­monitored. An output will not switch until both the cor­
responding inputs are "1".

}

Switch­off (brake is applied):

O1+/O1­ is switched off safely when there is a "0" signal (0 VDC) at Y10 and/or
Y11.

O2+/O2­ is switched off safely when there is a "0" signal (0 VDC) at Y20 and/or
Y21.

INFORMATION

Please note that when using fast shutdown, the inputs for slow shutdown
(S35 and S36) must have a "1" signal.

Power circuit 1 Y10

Y11

O1+, O1­

1

1

1

Load under current (power circuit 1
switched on)

1

0

0

Load without current (power circuit
1 switched off)

0

1

0

0

0

0

Power circuit 2 Y20

Y21

O2+, O2­

1

1

1

Load under current (power circuit 2
switched on)

1

0

0

Load without current (power circuit
2 switched off)

0

1

0

0

0

0

The power circuits are supplied via the terminals B1/B2 with the voltage U

B1B2

 (voltage

range: rated voltage 24, 48 VDC).

INFORMATION

Max. current at the power circuits

It is essential to note that the effective current at terminals B1/B2 to supply
the power circuits must not exceed 10 A. The cables must be fitted with a
10 A fuse, characteristic B/C.

Both poles are switched (e.g. O1+, O1­).
