Technical details
Operating Manual PNOZ s50
1002194­EN­02 63
Environmental data 751500
Climatic suitability EN 60068­2­1, EN 60068­2­14, EN 60068­2­2, EN
60068­2­78
Ambient temperature
Temperature range 0 ­ 55 °C
Storage temperature
Temperature range ­40 ­ 85 °C
Condensation during operation Not permitted
EMC EN 61000­4­2, EN 61000­4­3, EN 61000­4­4, EN
61000­4­5, EN 61000­4­6, EN 61000­4­8, EN
61326­3­1
Vibration
In accordance with the standard EN 60068­2­6
Frequency 10,0 ­ 55,0 Hz
Amplitude 0,35 mm
Max. operating height above sea level 2000 m
Airgap creepage
In accordance with the standard EN 60664­1
Overvoltage category III
Protection type
Mounting area (e.g. control cabinet) IP54
Housing IP20
Terminals IP20
Potential isolation 751500
Potential isolation between 2­pole semiconductor outputs and system
voltage
Type of potential isolation Basic insulation
Mechanical data 751500
Mounting position Horizontal on top hat rail
Material
Bottom PC
Front PC
Top PC
Connection type Spring­loaded terminal
Mounting type plug­in
Conductor cross section with spring­loaded terminals:
Flexible with/without crimp connector
0,20 ­ 2,50 mm², 24 ­ 12 AWG
Spring­loaded terminals: Terminal points per connec­
tion
2
Stripping length 9 mm
Dimensions
Height 100,0 mm
Width 45,0 mm
Depth 120,0 mm
Weight 260 g
The standards current on 2013­03 apply.
