L OCAL M ODE
Description: Returns the FM5004 to local mode when it is in
remote mode. Local mode allows the operator to use
the front panel buttons.
Syntax: LOCL,x
Parameters: Local mode enable (x):
• 0 = disabled; stays in remote mode
• 1 = local mode enabled
Example: To return the FM5004 to local mode:
LOCL,1
The front panel buttons will become operational and
the FM5004 will return:
LOCL,1
L OG S CALE
Description: Enables either a logarithmic or linear scale for the
analog output voltage.
Syntax: LOGS,x
Parameters: Log scale enable (x):
• 0 = log scale disabled (linear scale enabled)
• 1 = log scale enabled
Example: To set the analog output voltage to log scale:
LOGS,1
The scale will change to logarithmic scale and the
FM5004 will return:
LOGS,1
