SYSTEM STATUS
Displays the following information:
• Software Revision
• Software Date
• +5V Buss Voltage
• +12V Buss Voltage
• -12V Buss Voltage
The acceptable values for the buss voltages are +/-10% of nominal. If the
measured voltages are outside of this range, contact ETS-Lindgren.
SAMPLES/SEC
Calls the numeric entry screen to select the field measurement sample rate in
samples per second. The minimum sample rate is one sample per second. The
maximum sample rate is determined by the FM5004 and is based on the speed
of the connected probes. The maximum rate is limited to the slowest probe that is
communicating with the FM5004.
When the FM5004 is in 3-axis mode, the actual sample rate for a
complete measurement of the probe field is 1/6 of the selected
sample rate.
KEY CLICK
If selected, the FM5004 alarm will emit a short pulse each time a key is pressed.
ALARM SILENCE
To silence the alarm temporarily when in latched mode, position the arrow to the
left of this item and press Enter. However, if the parameter that caused the alarm
to occur is still outside of the alarm limits, the alarm will still latch on when the
menu system is exited.
To silence the alarm permanently, the alarm must be disabled in the alarm setup
section or the probe must be disconnected or turned off.
