D ISPLAY F ORMAT
Description: Sets the format for the FM5004 display.
When a command is sent to enable a display format,
the previous format will become disabled. If all modes
are turned off, the display will become inactive (blank).
In the case of the 4-probe display mode, only the
m and x parameters are required.
When setting the display to 2-line mode, a separate
command is required to define each line.
Syntax: DSFM,m,n,x
Parameters: Display format (m):
• 1 = 2-line, line 1 display
• 2 = 2-line, line 2 display
• 3 = 3-axis display
• 4 = 4-probe display (n parameter not used)
Display mode (n):
• 1 = probe 1 (3-axis format) or minimum of probes
(2-line format)
• 2 = probe 2 (3-axis format) or maximum of probes
(2-line format)
• 3 = probe 3 (3-axis format) or average of probes
(2-line format)
• 4 = probe 4 (3-axis format) or analog output
(2-line format)
Numeric value (x):
• 0 = mode disabled
• 1 = mode enabled
