LINE 1
• MIN OF PROBE The minimum of the current reading and the
previous samples for the display-selected
probes will display on line 1.
• MAX OF PROBE The maximum of the current reading and the
previous samples for the display-selected
probes will display on line 1.
• AVERAGE OF PROBE The average of the current reading and the
previous samples for the display-selected
probes will display on line 1.
• ANALOG OUT • The readings sent to the analog output
system will display on line 1. The number
will be an average of the current reading
and previous readings.
• The number of previous readings is
determined from the filter size setting in
the Analog Out Setup menu.
• For example, if filter size is set to 10, the
number displayed is an average of the
current reading plus the nine previous
readings. This number will be updated at
the display update rate.
LINE 2
• MIN OF PROBE The minimum of the current reading of all
probes attached and the previous samples
for the display-selected probes will display
on line 2.
