Entry field Purpose Available Options Choice made
Word 0
Value of Word# 0,
when enabled.
Text field to enter user-
defined value
(available when Word
0 is enabled)
283* (Refer to)
Mask 0
Value of mask for
word0
Text field to enter user-
defined value
(available when Word
0 is enabled)
000
Enable Word 0 or
Inverse of Word 0
Whether word 0 or the
inverse of it will be
used
• True
• False
False
Enable Seq 0
Whether Seq0 will be
used.
• True
• False
False
Seq 0 Value of Seq 0
Text field to enter user-
defined value
(available when Seq 0
is enabled)
N/A since Seq0 is not
enabled
Gap Count Gap Count for Seq0
Text field to enter user-
defined value
(available when Word
0 is enabled)
N/A since Seq 0 is not
enabled
Enable Alt Seq 0
Whether Alternate of
Seq0 will be used
• True
• False
False
Alt Seq 0
Value of Alternate of
Seq 0
Text field to enter user-
defined value
(available when Alt
Seq 0 is enabled)
N/A since Alt Seq 0 is
not enabled
Enable Word 1
Similar to Word 0, Seq
0 etc.
• True
• False
False
Word 1
Text field to enter user-
defined value
(available when Word
0 is enabled)
N/A since Word 1
Mask 1
Text field to enter user-
defined value
(available when Word
0 is enabled)
000
Enable Word 1 or
Inverse of Word 1
• True
• False
False
Enable Seq 1
• True
• False
False
Seq 1
Text field to enter user-
defined value
(available when Seq 0
is enabled)
N/A since Seq0 is not
enabled
Gap Count
Text field to enter user-
defined value
(available when Word
0 is enabled)
N/A since Seq 0 is not
enabled
Enable Alt Seq 1
• True
• False
False
UG028, July 1, 2014 67
