RS-232 to 2.5mm Cables
1 included
Dimensions
17 ¼ x 1 ¾” x 9 ¼”
(W x H x D)
438mm x 44mm x 235mm
Weight
5.44 lbs. (2.47kg)
Installation
This section will provide you with a starting point for installing the TheaterLinX.
Before installing TheaterLinX, you will need to:
1.
Get a basic DigiLinX system up and tested. This should include a SwitchLinX, a
PowerLinX, a couple of SpeakerLinX, and a MediaLinX.
2.
Connect the Receiver to the sources you have decided to use in the home theater.
NOTE:
Note which device is going into which source input on the Receiver.
3.
Test both systems. This will validate that all your connections are correct.
Connecting the TheaterLinX to your Receiver
The TheaterLinX will input and output stereo audio to the Receiver (the TheaterLinX
is a stereo only device not designed to handle multi-channel audio).
1.
For the Receiver to receive audio from the TheaterLinX, connect either the Analog
Out or the S/PDIF Out to a source input on the Receiver using an RCA cable.
2.
Connect the TheaterLinX Analog Input or S/PDIF (two channel) Input to a fixed
line level output such as a Tape Out on the Receiver using an RCA cable.
If you connected Analog Out and Analog In, your setup should look something like
what is displayed in the following diagram:
