DigiLinX Installation and Design Guide
12-6
All specifications subject to change without notification. All rights reserved. Copyright © 2008 NetStreams
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
3600 W. Parmer Lane, Suite 100; Austin, TX 7872
4.
Connect the Ethernet port.
5.
Connect S/PDIF and Analog Audio.
6.
Connect power.
VL9100-CS can be rack mounted using the included rack ears.
1.
Install the ViewLinX using the ears provided.
2.
Connect the video inputs (BNC to VGA or RCA adapters maybe required
depending on your source)
3.
Connect the Ethernet port.
4.
Connect the audio connector (balanced, S/PDIF, or analog)
5.
Connect power.
