Serial Cable to PC Serial Port* Monitor Cable to Video Monitor (optional)
DB906 -- 2 m (6') BNC06 -- 2 m (6')
DB915 -- 5 m (15') BNC15 -- 5 m (15')
DB930 -- 9 m (30') BNC30 -- 9 m (30')
14.4 Mounting the Controller
Mount the controller to a Banner controller mounting bracket or to a flat surface using its four mounting flanges, as
shown below. Allow a minimum of 75 mm (3") of clearance for cable bend relief.
The following mounting hardware is supplied with the controller.
• Four M5 x 0.8 x 14 mm socket head cap screws
• Four M5 x 0.8 hex nuts
• Four split lock washers
• Four flat washers
• Short-arm hex key wrench
DIN Rail Mounting Option
Mount the controller to a DIN rail using Banner controller mounting bracket SMBPPDH for flat mounting, or SMBPPDE
for edge mounting. Hardware for fastening the bracket to the controller is included with the bracket.
14.5 Mounting the Camera
Use the appropriate Banner Camera Model with the Banner controller:
Standard ProII Camera Model Number ProII Controller Model Number ProII Model Type
PPROCAM PPROCTL Gray Scale
PPROCAM1.3 PPROCTL1.3 High Resolution
PPROCAMC PPROCTLC Color
Mount the camera to a Banner camera mounting bracket or to a flat surface. The camera has six M3 threads (two on
the top and two on each side) and one 1/4-20 UNC thread on its base.
Cable Bend Relief
If using a straight cable, allow at least 75 mm (3") clearance at the rear of the camera for cable bend relief. If using a
right-angle cable, allow at least 50 mm (2").
Mounting Hardware
The following mounting hardware is supplied with all brackedts:
• Four M3 x 0.5 x 6 mm socket head cap screws
• Four medium split lock washers
• Four flat washers
• Short-arm hex key wrench
Camera Mounting Brackets
Mount the camera with a U-Bracket, Long U-Bracket, Right-Angle Bracket, or Knuckle Assembly Kit. Secure the
camera to the bracket with the supplied M3 screws.
