Page 18
Description
Icon
Copy Selected Tool
-- clones the selected tool.
Expand Button
Clicking on the Expand button (
) toggles the size of the Navigation/Results window to accommodate an expanded
list of inspection results files, as shown below.
2.2.4 Configuration Window
The Configuration window, on the right side of the screen, displays the currently selected options with multiple tabs.
Clicking the Setup, Tools, Teach, Run, System, Save, or Help buttons on the Main Menu toolbar changes the contents
of the Configuration window accordingly.
Banner Engineering Corp.
Minneapolis, MN USA
18
2/2010
System Description
