80 Publication IASIMP-QS011B-EN-P — January 2009
Chapter 6 Motion FactoryTalk View Integration
Download Fonts to the Terminal
Because PanelView Plus terminals do not include the Arial Bold font when shipped but the
FactoryTalk View ME applications require this font, it is necessary to download Arial Bold from
your personal computer to the PanelView Plus terminal.
Follow these steps to download fonts to the PanelView Plus terminal.
1. Apply power to the PanelView Plus terminal.
2. Connect your Ethernet cable between your PanelView Plus terminal and personal computer.
3. Choose Tools>Transfer Utility.
The Transfer Utility window
opens.
4. Click … to browse for the source
font file.
The Select File to Download
window opens.
5. Navigate to C:\WINDOWS\Fonts.
6. Select True Type Font Files in the
Files of type field.
7. Enter ‘Arialbd.ttf’ in the File name
field.
8. Click Open.
