Page 115: Troubleshooting, Section on, Appendix

115
Publication IASIMP-QS011B-EN-P — January 2009
115
Appendix
C
Troubleshooting
This appendix provides troubleshooting information for the logic provided in the application
template only.
•
Troubleshooting information for the manual cycle starts on this page.
•
Troubleshooting information for the automatic cycle starts on
.
Troubleshooting the Manual Cycle
Follow these steps for assistance with problems experienced during use of the manual cycle of
the CompactLogix program template.
Determine Where the Program Fails
The first step in troubleshooting the code within application template is to determine where the
program fails or stops. The manual cycle is controlled by a state machine. The current state of
this state machine is indicated by the value in the controller tag ManualCycle.StepIndex. Perform
the following steps to determine where the program is failing.
For assistance with
Refer to this manual
Drive faults and fault codes
Ultra3000 Digital Servo Drive Installation Manual,
publication
Network faults and fault codes
DeviceNet Modules in Logix5000 Control Systems User Manual,
publication
TIP
You must be online with the CompactLogix controller in the Run Mode.
Your HMI also must be running in order to issue the commands to the controller.
