Chapter 2 Hardware Selection
Verify Base System Performance Specifications
This section provides system combination information for the Ultra3000 drives when matched
with MP-Series low-inertia motors. Included are motor power, feedback, and brake cable catalog
numbers, system performance specifications, and torque/speed curves. Refer to the Kinetix
Motion Control Selection Guide, publication
GMC-SG001 , for additional motor/drive performance
specifications.
Refer to the following table to determine the appropriate cables needed for your Ultra3000 drive
and motor combination.
(1) Use connector kit (catalog number 2090-UXBB-D15M) or panel-mounted breakout components on drive end. Refer to the Kinetix Motion Control Selection Guide,
publication
GMC-SG001 , for catalog numbers.
(2) Premolded (drive end) feedback cables (catalog number 2090-UXNFBMP-Sxx) are also available for Ultra3000 drives.
Motor end connector kits are available for motor power, feedback, and brake cables. Refer to the Kinetix Motion Control Selection Guide, publication GMC-SG001 , for catalog
numbers.ttt Cable length xx is in meters.
400/460V System Performance Specifications
200/230V System Performance Specifications
Ultra3000 Servo Drive Motor Type Motor Power Cable Motor Feedback Cable Motor Brake Cable
2098-DSD-HV030X-DN MPL-B310P
2090-XXNPMF-16Sxx
2090-XXNFMF-Sxx (1) (2)
Absolute High-resolution
Feedback
2090-UXNBMP-18Sxx
2098-DSD-010X-DN MPL-A310P
Motor
Max
Speed
rpm
System
Continuous
Stall Current
A 0-pk System
Continuous
Stall Torque
N•m (in•lb)
System Peak
Stall Current
A 0-pk System Peak
Stall Torque
N•m (in•lb)
Motor
Rated
Output
kW
Ultra3000 460V Drives
MPL-B310P 5000 2.4 1.58 (14) 7.1 3.61 (32) 0.72 2098-DSD-HV030X-DN
Motor
Max
Speed
rpm
System
Continuous
Stall Current
A 0-pk System
Continuous
Stall Torque
N•m (in•lb)
System Peak
Stall Current
A 0-pk System Peak
Stall Torque
N•m (in•lb)
Motor
Rated
Output
kW
Ultra3000 230V Drives
MPL-A310P 5000 4.85 1.58 (14) 14 3.61 (32) 0.73 2098-DSD-010X-DN
