4 • Set up Your System Architecture
59
PowerMonitor 500 Unit
Connects to an Allen-Bradley PowerMonitor 500 panel-mounted meter by using the
Modbus RTU master driver integral to FactoryTalk EnergyMetrix software.
PowerMonitor 500 units can connect to the FactoryTalk EnergyMetrix server using serial
multidrop (RS-485) or Ethernet communication (using a serial to Ethernet gateway).
PowerMonitor 3000 (model) Unit on (communication type)
Connects to an Allen-Bradley 1404 PowerMonitor 3000. The following are supported:
Models
 M4 and M5 - basic power and energy metering
 M6 - basic power quality metering
 M8 - advanced power quality metering
Communication Types
 ControlNet network.
 DeviceNet network.
 Ethernet network - the older Ethernet protocol, also known as CSP or PCCC, used
with the Series A Ethernet PowerMonitor 3000 unit.
 EtherNet/IP network - also known as CIP, used with the Series A Ethernet
PowerMonitor 3000 unit. Uses DeviceNet network addressing.
 Remote I/O network - Must have a parent device such as a PLC-5, SLC 500 or
ControlLogix controller.
 Serial network - Allen-Bradley DF1 half duplex master/slave.
PowerMonitor 1000 (model) Unit on (communication type)
Connects to an Allen-Bradley 1408 PowerMonitor 1000 unit. The following are
supported:
Models
 TR1 - voltage/current transducer
 TR2 - power transducer
 EM1 - real energy submetering monitor
 EM2 - energy and demand monitor
 EM3 - full function power and energy monitor
Communication Types
 EtherNet/IP network
 Serial network - Allen-Bradley DF1 half or full duplex
Serial communication will not provide adequate performance in most cases. Please
contact Rockwell Automation technical support for more information.
