FactoryTalk EnergyMetrix Software
162
The calculated demand for total apparent power.
 Projection Data
The calculated projected values for current, power, reactive power and apparent
power.
Input/Output Tab
This displays real-time data from an Allen-Bradley PowerMonitor 5000 Unit.
 Status Inputs
This shows the current state of the configured status inputs. A highlighted indicator
means the external contact wired to that status input is closed. A dark indicator means
the external contact wired to the status input is open.
 Status Input Counters
This counts the number of times the Status Input closed. To reset any counter to zero,
click the Reset button next to the counter field.
 Relays
This shows the current state of relays, based on configured settings. A highlighted
indicator means the relay is energized. A dark indicator means the relay is de-
energized or restored to its normal state.
 To force a change in state, click either Close or Open.
 The status of the relay is displayed, for example, ‘Forced Energized’.
 To cancel the manual relay override and return the relay to configured operation,
click Release.
 Reset Counter Button
This resets the associated counter to zero. If the Reset button does not operate and the
text is gray, this power monitor has been configured to not allow counter resets. Refer
to the device configuration
 Close (Relay) Button
This manually forces a relay closed.
 Open Button
This manually forces a relay open.
 Release Button
This cancels the relay manual override and returns the relay to configured operation.
The demand values are displayed for the most recent complete
demand interval.
