9 • ReportsPlus
255
NestedGroups Collection
The NestedGroups object is similar to the Report.Groups object in that it contains a
collection of Group objects. However, Report.Groups is a flat array of Groups, while
Report.NestedGroups is a hierarchical collection of Group objects that mimics the tree
structure of the report selection tree. The members of the collection are selected in the
MPR setup. See
Selecting Groups and Meters in the MPR on page 226 for more
information.
Instancing
The NestedGroups object is a creatable object.
Accessing
The Report object automatically creates one NestedGroups object (accessible using the
Report.NestedGroups property) and MPR script code can create additional Groups objects
if needed.
Using nested groups requires recursion to traverse all selected children groups. See the
example below.
Properties
Example
The following sample MPR script demonstrates the use of recursion to select nested
groups.
Dim grid As New Grid
Dim row As Row
Sub Main()
Dim group As Group
Dim col As Col
col = grid.AddCol("Name") : col.Width = 10
' First call of recursive procedure
For Each group in Report.NestedGroups
row = grid.AddRow()
row(0) = group.Name
BuildNestedGroupsGrid(group, " ")
Next group
Report.Add(grid,0,0)
End Sub
Sub BuildNestedGroupsGrid (parentGroup As Group, tabSpace As
String)
Dim group As Group
' Add children groups to grid and call itself recursively
For Each group in parentGroup.Groups
row = grid.AddRow()
Property R/W Description
Group(index) As Group R Collection of Group objects that represent the
groups that are selected in the report's groups/
meters tree
