9 • ReportsPlus
235
Methods
Enums
Example
This example Multi-Purpose Report script creates a chart with three data series. The first
two data series will be displayed as stacked bars and the third data series will be displayed
as a normal bar next to the stacked bars.
Dim barChart As New BarChart()
barChart.AddData("Jan", 100)
barChart.AddData("Feb", 200)
barChart.AddData("Mar", 300)
barChart.NextSeries
barChart.SeriesStacked = true
barChart.AddData("Jan", 5420)
barChart.AddData("Feb", 3500)
barChart.AddData("Mar", 10405)
barChart.NextSeries
barChart.AddData("Jan", 3340)
barChart.AddData("Feb", 5200)
barChart.AddData("Mar", 1500)
Report.Add(barChart, 3, 2, 5, 3)
Col Object
The Col object represents one column in a Grid object
Method Description
BarChart() As BarChart Create a BarChart object
AddData(Data As
Double) Add a data point to the bar chart
AddData(Timestamp As
DateTime, Data As
Double) Add a time series data point to the bar chart
NextSeries() Close the current data series and create a new one. This is
used when the bar chart will contain multiple data series.
When a BarChart object is created, the first series is
automatically opened so this method should not be called if
the bar chart is only to display one series
Constant Description
ChartType.Bar
ChartType.Gantt
ChartType.Trend Specifies a chart type
