FactoryTalk EnergyMetrix Software
190
Group Button
Select the group of which the desired meter is a member.
View Data Button
Select By meters to view an individual meter. Select By groups to aggregate a group's
meters into a single trend line.
Meter Button
Select the desired meter from the pull-down menu. This field is disabled (grayed-out) if By
groups is selected.
Meter Tag Button
Select the meter tag from the pull-down menu.
Start Date Button
Select a start date from the calendar. You can select the same or different start dates for
different pens.
Summary Type Button
A summary type of None returns a simple trend of the meter tags over the selected Day
range. A summary type of Average Sunday through Average Saturday returns a one-day
trend with the average values for that day over the selected Day range.
Add - Cancel Buttons
Click Add to save your configuration selections or Cancel to discard them.
Plot
Click Plot to retrieve data from the database and generate the trend chart.
Global Navigation Buttons
These buttons adjust the start date earlier or later by the duration of the Day range.
Local Pen Navigation Buttons
 Select/Edit
Click the colored button to the left of the tag name to open the pen configuration
dialog box.
 H
Click this button to hide the pen.
 X
Click this button to delete the pen.
