Appendix a: specifications and dimensions, Specifications and dimensions, Appendix – Rockwell Automation MPMA Integrated Multi-Axis Linear Stages User Manual
Page 81
Rockwell Automation Publication MPMA-UM001B-EN-P - November 2010
81
Appendix
A
Specifications and Dimensions
This appendix is a supplement to this document. Associated Kinetix publications
listed in
and information in product
specifications may supersede the information in this appendix.
Topic
Page
MPMA-xABxxxxxx-xxx Product Specifications and Dimensions
MPMA-xACxxxxxx-xxx Product Specifications and Dimensions
MPMA-xAPxxxxxx-xxx Product Specifications and Dimensions
MPMA-xCBxxxxxx-xxx Product Specifications and Dimensions
MPMA-xCQxxxxxx-xxx Product Specifications and Dimensions
MPMA-xBExxxxxx-xxx Product Specifications and Dimensions
MPMA-xBIxxxxxx-xxx Product Specifications and Dimensions
MPMA-xBDxxxxxx-xxx Product Specifications and Dimensions
Brake Specifications for Ball Screw Linear Stage Motors
Environmental Specifications for Multi-axis Stages
