Rockwell Automation Publication MPMA-UM001B-EN-P - November 2010
65
Chapter
8
Removing and Replacing Multi-axis Stage
Components
Introduction
This chapter provides procedures for user-replaceable parts on the multi-axis
stage. Procedures for the cover, and the rotary motor replacement are limited to
the secondary stage. Return your multi-axis stage to factory for the cover and the
rotary motor replacement for the base stage.
Topic Page
Before You Begin 66
Cable Carrier Assembly Removal Procedures 66
Cable Carrier Assembly Installation 69
Remove the Strip Seal 69
Remove the Cover 70
Install the Cover 70
Replace the Strip Seal 71
Install the Side Cover 72
Replace the Rotary Motor 73
ATTENTION: Lock out and tag out input power before
servicing.
These procedures are not applicable to both types of linear stages.
Direct drive and ball screw linear stages have unique
configurations.
