Rockwell Automation Publication MPMA-UM001B-EN-P - November 2010
31
Chapter
4
Mounting and Connecting the MP-Series
Integrated Multi-axis Linear Stage
Introduction
This chapter provides unpacking, handling, and mounting instructions.
Unpacking, Handling, and
Inspection
Inspect packaging to make certain no damage has occurred in shipment. Any
damage or suspected damage should be immediately documented. Claims for
damage due to shipment are usually made against the transportation company.
Contact Rockwell Automation immediately for further advice.
Topic
Page
Unpacking, Handling, and Inspection
About the Air Option for Ball Screw Linear Stages
About the Brake Option for Ball Screw Linear Stages
Meeting UL Installation Standards
IMPORTANT
Any person that teaches, operates, maintains, or repairs these multi-
axis stages must be trained and demonstrate the competence to
safely perform the assigned task.
