Additional HART Protocol Information C-13
63
Read analog output
information
0
Analog output number
code
—
0
Analog output number
code
—
1
Analog output alarm
select code
2
Analog output transfer
function code
3
Analog output range
units code
4…7
Analog output upper
range value
(F)
8…11
Analog output lower
range value
12…15 Analog output
additional damping
value (seconds)
64
Write analog output
additional damping
value
0
Analog output number
code
—
—
As in command
—
1…4
Analog output
additional damping
value (seconds)
(F)
65
Write analog output
range value
0
Analog output number
code
—
—
As in command
—
1
Analog output range
units code
2…5
Analog output upper
range value
(F)
6…9
Analog output lower
range value
66
Enter/edit fixed
analog output mode
0
Analog output number
code
—
—
As in command
—
1
Analog output units
code
2…5
Analog output level
(4)
(F)
67
Trim analog output
zero
0
Analog output number
code
—
—
As in command
—
1
Analog output units
code
2…5
Externally measured
analog output level
(F)
Table C.6 Common Practice Commands
Command
Data in Command
Data in Reply
#
Function
Byte
Data
Type
(5)
Byte
Data
Type
(5)
