Industrial 18.1" Flat Panel Monitor 61
Publication 6185-UM001B-EN-P
Specifications (6185-V)
Display
Type
Active Matrix Color Thin Film Transistor (TFT) LCD
Backlight
Type
Life Expectancy
Field Replaceable
Cold Cathode Tubes (CCT) (8 bulbs)
50,000 hours (mean for 1/2 brightness point)
No
Nominal Display Area
Diagonal
Horizontal
Vertical
18.1 in. (460 mm)
14.1 in. (359 mm)
11.3 in. (287 mm)
Resolution 1280x1024 pixels, full color
Viewing Angle (CR ≥ 10)
Horizontal (typical)
Vertical (typical) +/-85 deg.
+/-85 deg.
Luminance (typical) 200 nit, 58 fL (screen overlay option will reduce
luminance)
Contrast Ratio (typical) 150:1
CIE coordinates - White x=0.315, y=0.329
Response Time 45 msec (typical)
Video
Supported Standards
720x400 at 70 Hz (VGA text)
640x480 at 60 Hz and 75 Hz
800x600 at 60 Hz and 75 Hz
1024x768 at 60 Hz and 75 Hz
1280x1024 at 60 Hz and 75 Hz (native)
Video Bandwidth 135 MHz (max video dot clock)
Video Input Signal RGB analog (white level = 0.714V above ref. black,
into 75 Ohms, single ended)
Sync Input Signals Separate horizontal and vertical sync (TTL signal
levels), sync on green (0.285V below ref. black), or
composite sync.
Input Connection Female HD-15
5-BNC connector support through cable adapter
Controls and Indicators
On-Screen Display
Horizontal size, vertical position, horizontal position,
contrast, brightness, clock phase, color balance, and
video information
Operator Input Touchscreen Option - Resistive or capacitive
touchscreen, with serial RS-232 interface controller
and DOS and Windows 95/98/2000 or NT drivers.
Other OS drivers are available.
Electrical
Line Voltage
90 to 264 VAC or 12 VDC
Line Frequency 47-70 Hz or DC
